IMO No. 9797931
Main Particulars
Length Overall
71.000M
Breadth mld.
13.00 M
Depth mld.
5.00 M
Draught Loaded
3.50 M
Gross Tonnage
1389.00 T
Net Tonnage
417.00 T
Compliment
6 crew + 4 Off
Speed
8 Kn.
Capacities
Cargo
2100 KL
Fuel Oil
30.0 T
Fresh Water
50.0 T
Classification
IRS SUL OIL TANKER(Sea Going) for Carriage of Petroleum Product having flash Point above 60°
Main Engines
2 x 500 BHP NT 855 M Cummins Diesel engines
Gear Boxes
ZF make hydraulic reverse reduction boxes.
Generators
2 x 100 KVA, 1 x 62.5 KVA
Cargo Pumps
2 x 225 M^3/hr gear pumps driven off Diesel Engine 105 BHP each
Cargo Tanks
8 Nos.
SALIENT FEATURES
- Double Skin construction
- Totally clean cargo tanks.
- Flat Deck
- Can carry 2 grades of cargoes with double segregation in the pipe line.
- Gear pumps which can pump up to 380 CST products and pumping capacity of 2 x 225M^3/hr at a head of 25.0 M.
- Independent discharge and loading manifolds on Port & Stbd. Sides.
- Fitted with approved type Drip Sampler and flow meter.
- Fully classed with IRS as a Tanker Barge with Restricted Load line.
- Electro hydraulic steering gear.
- Electrically operated remote control for the main engines & gear boxes.
- Electro hydraulic anchor windlass.
- Heating coils to heat the cargo upto 55 degrees C
- Cranes - 2 x 1.0 T davit for cargo hose
- 2 Nos Yokohama fenders
- Boiler and heating coils of sufficient capacity to maintain the temperatue of FO 380 CST
- Fully Air conditioned Wheel house and accomodation for crew members
